REPAIR INSTRUCTIONS 2. Remove the two 12-point capscrews (3) that retain camshaft thrust washer (1). Camshaft may have to be rotated slightly to make the capscrews accessible through openings (2) in the camshaft drive gear (4).
146
147
Figure 146 — Auxiliary Driveshaft Oil Metering Plug 1. Correctly Installed Oil Metering Plug
Camshaft Removal
Make sure all loose components are secured to, or removed from, the engine before rotating engine on the stand. Failure to do so may result in damage to components or severe personal injury. 1. Rotate engine so that the deck surface is downward and the oil pan rail is upward (engine inverted). Figure 147 — Camshaft Thrust Washer Capscrews
When the engine is rotated, the valve lifters will fall downward into the push rod holes but will be captured by their heads. They will be out of the way for camshaft removal. Refer to Figure 147.
Page 116
1. Thrust Washer 2. Openings
Refer to Figure 148.
3. Capscrew, 12-Point 4. Camshaft Drive Gear
