3500 ENGINE
SPECIFICATIONS
FLYWHEEL HOUSING
Make reference to FLYWHEEL HOUSING RUNOUT and FLY-WHEEL HOUSING BORE for the correct methods of flywheel housing inspection (1) Torque for plugs ........................70 + 15 N-m (50 + 11 lb. ft.) (2) Install three dowels to a height of .....................................6.0 + 0 5 mm ( 24 + .02 In.) (3) Tighten the bolts that hold the flywheel housing to the engine block evenly See FLYWHEEL HOUSING BOLT INSTALLATION CHART for correct position Torque for 1/2"-13 NC bolts ...........................................100 + 14 N-m (75 + 10 lb ft.) Torque for 5/8"-11 NC bolts ...........................................200 + 25 N-m (150 + 20 lb ft.)
NOTE: FOR TORQUE VALUES NOT GIVEN, SEE THE FIRST PAGE OF SPECIFICATIONS FOR GENERAL TIGHTENING TORQUES 51
