3500 ENGINE
SPECIFICATIONS
FLYWHEEL (1N3565 & 7N5014) Make reference to FLYWHEEL RUNOUT for the correct method of flywheel inspection. (1) (2) (3)
Crankshaft. Flywheel. Put 2P2506 Thread Lubricant on all the bolt threads that hold the flywheel to the crankshaft and tighten to a torque of .............................1150 + 60 N-m (840 + 44 lb. ft.)
NOTE: When flywheel is installed, put dash mark on flywheel (near pilot bore) in alignment with dash mark on crankshaft.
FLYWHEEL RUNOUT Face Runout (axial eccentricity) of the Flywheel: 1 2 3 4
Install the dial indicator as shown Put a force on the flywheel toward the rear Set the dial indicator to read 0 0 mm ( 000 in ) Turn the flywheel and read the indicator every 90 Put a force on the flywheel to the rear before each reading The difference between the lower and higher measurements taken at all four points must not be more than 0 15 mm ( 006 in ) which is the maximum permissible face runout (axial eccentricity of the flywheel)
CHECKING FACE RUNOUT OF THE FLYWHEEL (TYPICAL EXAMPLE)
48
