3500 ENGINE

SPECIFICATIONS

LOWER FRONT GEAR GROUP

(1) (2) (3) (4)

(5)

(6)

Drive gear for water and oil pumps.

Idler gear.

Crankshaft gear.

Bore in bearing (after assembly) ..........................106.000 _ 0.065 mm (4.1732 _ .0026 in.)

Diameter of shaft (new) .................................105.880 ± 0.020 mm (4.1685 + .0008 in.)

Bore in bearings (after assembly) ..........................75.000 _ 0.055 mm (2.9528 _ .0022 in.)

Diameter of shaft (new) .................................74.900 + 0.015 mm (2.9488 + .0006 in.)

Thickness of thrust washer (new) .....................8.50 + 0.05 mm (.335 _ .002 in.)

Width of groove in shaft (new) ........................8.750 _ 0.025 mm (.3445 + .0010 in.)

End play for shaft ..................................0.175 to 0.325 mm (.0069 to .0128 in.)

NOTE: FOR TORQUE VALUES NOT GIVEN, SEE THE FIRST PAGE OF SPECIFICATIONS FOR GENERAL TIGHTENING TORQUES 43
