3500 ENGINE
SPECIFICATIONS
FRONT BALANCER GROUP
(1) (2)
(3) (4) (5)
Balancer gear. Diameter of shaft (new) ..................................74 900 + 0 015 mm (2 9488 + .0006 in ) Bore in bearing (after assembly)...........................75 000 + 0.053 mm (2 9528 + .0021 in ) Bearing joint must be in center of heavy section in gear at assembly. Balancer gear marks must be in alignment with crankshaft gear marks as shown for SAE standard rotation engines Balancer gear marks must be in alignment with crankshaft gear marks as shown for SAE opposite rotation engines Crankshaft gear.
NOTE: FOR TORQUE VALUES NOT GIVEN, SEE THE FIRST PAGE OF SPECIFICATIONS FOR GENERAL TIGHTENING TORQUES
