3500 ENGINES
DISASSEMBLY AND ASSEMBLY CYLINDER HEADS
9.
Remove a section of water manifold (12) and elbows (13) from the cylinder head
10.
Remove the bolts that hold air inlet elbow (15) and exhaust manifold (14) to the cylinder head.
11.
Fasten a hoist to cylinder head (16) with tooling. Remove bolts (17) and (18) to remove cylinder head (16) from the engine. The weight of the head is 45 kg (100 lb.).
12.
Remove head gasket (19) and the seals from the spacer plate. Remove spacer plate (20) and the gasket from the cylinder block.
378
