3500 ENGINES
DISASSEMBLY AND ASSEMBLY FUEL INJECTION CONTROL LINKAGE
INSTALL FUEL INJECTION CONTROL LINKAGE Tools Needed 1P510 Driver Group 9S9082 Engine Turning Pinion
1269-12 A 1
B 1
1
Use tool group (A) to install the bearings in bracket assemblies (1) until they are in the center of their bores. Check the bore in the bearings after assembly. The bearing bores must be 21.925 ± 0.015 mm (.8632 ± .0006 in.).
2.
Install two bracket assemblies (1) on each side of the 3512 Engines. Install one bracket assembly (1) on the 3508 Engines.
3.
Install control shaft (2) on each side of the engine block.
4.
Use tool group (A) and install the bearings in the center of the bores in supports (3). Check the bore in the bearings after assembly. The bearing bores must be 21.925 ± 0.015 mm (.8632 ± .0006 in.).
374
