3500 ENGINES
DISASSEMBLY AND ASSEMBLY FUEL INJECTION CONTROL LINKAGE
REMOVE FUEL INJECTION CONTROL LINKAGE 1269 Tools Needed 1P510 Driver Group 9S9082 Engine Turning Pinion
A 1
B 1
start by: a) remove rocker shafts and push rods
b)
remove front drive housing
1.
Remove the bolts that hold the brackets for shaft (2) to the front of the cylinder block. Disconnect the levers on shaft (2) from the levers on shafts (1) and remove shaft (2) from( the engine.
2.
Remove levers (4) and (5) and brackets (3) from shaft (2).
3.
Remove bearings (6) from brackets (3) with tool group (A).
4.
Remove access covers (7) from over the camshafts.
371
