3500 ENGINES
DISASSEMBLY AND ASSEMBLY FLYWHEEL HOUSING
INSTALL FLYWHEEL HOUSING1157-12
5P9736
Tools Needed Link Bracket
A 2
1.
Install O-ring seal (1) on the engine block and put clean engine oil on it. 2. Put the flywheel housing gasket in position on the rear of the engine block. 3. Install two 5/8"-11 NC guide bolts (2) in the, engine block. 4. Fasten a hoist to flywheel housing (3) with_43056 tooling (A) and put the housing in position on the guide bolts. Install the bolts to hold the housing in position and tighten the bolts evenly. Remove the guide bolts and install the remainder of the bolts. 5. Cut the flywheel housing gasket even with the bottom of the cylinder block.-!_w 6. Fasten a hoist to the engine and lift the engine enough to remove the plates between the cylinder block and the oil pan. If the oil pan gasket is damaged, the engine will have to be removed from the oil pan to make a replacement of the gasket. Lower the engine on the oil pan and 430 remove the guide bolts from the oil pan. Install all of the bolts that hold the oil pan to the engine. 7. Put camshaft drive gears (4) in position on the ends of the camshafts. Install the plate and tachometer drive adapter assembly to hold the gears in position. Tighten the bolts evenly to a torque of 100 + 15 N-m (75 + 11 lb. ft.). Hit the plate and adapter assembly with a hammer3 and tighten the bolts again to the same torque. Do this until the torque does not change. 8. Install brackets (5) and (6) on the engine. NOTE: Any time the rear crankshaft seal and wear sleeve are removed, a new seal and sleeve must be installed.
end by:
b) install tachometer drive c) install crankshaft rear seal and wear sleeve’
a) install exhaust elbow
364
