3500 ENGINES
DISASSEMBLY AND ASSEMBLY HYDRAMECHANICAL SHUTOFF DRIVE
REMOVE HYDRAMECHANICAL SHUTOFF DRIVE
1P 1855
Tools Needed Pliers
A 1
start by: a) remove hydramechanical shutoff control b) remove tachometer drive
1.
Remove tube assemblies (1) and (2) from the shutoff drive housing assembly and the engine.
2.
Remove the bolts and remove shutoff drive housing assembly (3) from the flywheel housing.
3.
Use tool (A) to remove snap ring (5) and the washer from the end of drive gear (4). Remove drive gear (4) from the housing assembly.
4.
If necessary, remove dowels (6) from the housing assembly.
5.
Remove bearing (9) and seal (7) from the housing assembly. The bearing can be used to push the seal out of the bore.
6.
Remove two bearings (8) from the drive gear bore.
7.
If necessary, remove housing assembly.
8.
Remove gear assembly ( 11 ) from the end of the crankshaft.
dowels (10) from the
345
