3500 ENGINES
DISASSEMBLY AND ASSEMBLY HYDRAMECHANICAL SHUTOFF CONTROL
19.
Remove seal (34) from plate (33).
NOTE: Carefully remove driven gear (36) from sleeve (35) so brush (39) and spring (38) do not become lost.
20.
To remove the gerotor assembly, remove drive gear (37), driven gear (36) and sleeve (35) from the housing assembly.
21.
Remove brush (39) and spring (38) from driven gear (36).
22.
Use tool (B) to remove snap ring (43) and remove seat (42), spring (41) and plunger assembly (40) from the housing assembly.
23.
Remove O-ring seal (44) from the housing assembly.
337
