3500 ENGINES
DISASSEMBLY AND ASSEMBLY HYDRAMECHANICAL SHUTOFF CONTROL
REMOVE HYDRAMECHANICAL SHUTOFF CONTROL 1.
Disconnect tube assemblies (2) from diverter valve (3) and disconnect tube assemblies (1) from the shutoff control.
2.
Remove the bolts to remove cover (5), tube (4) and the diverter valve as a unit from the shutoff drive housing assembly and the shutoff control.
3.
Disconnect tube assemblies (6), (7) and (9) from the shutoff control. Remove the bolts and hydramechanical shutoff control (8) from the shutoff drive housing assembly.
4.
Remove coupling (10) from the end of the shut off drive gear.
332
