3500 ENGINES
DISASSEMBLY AND ASSEMBLY OIL PUMP
6.
Make sure dowels (5) and (8) are installed in cover assembly (6) so they extend 6 ± 0.5 mm (.236 ± .02 in.) above the surface of the cover assembly.
7.
Use tooling (A) and install bearings (7) in cover assembly (6) with the joints of the bearings in the positions as shown.
8.
Put cover assembly (6) in position and tighten the bolts to hold it to the body assembly.
9.
Make sure the two pins in cover assembly (9) are installed so they extend 6 ± 1 mm (.236 ± .039 in.) above the surface of the cover assembly. Install the gasket and cover assembly (9) on the pump.
10.
Put clean engine oil on valve spool (13). Install valve spool (13), spring (12), gasket (11), cover (10) and the bolts on the pump body.
11.
Install the gasket and adapter assembly (14) on the pump body. end by: a) install oil pump
