3500 ENGINES
DISASSEMBLY AND ASSEMBLY FUEL TRANSFER PUMP
8.
Use tool group (A) to install the check valve in head (11) until it makes contact with the shoulder in its bore. Make sure the spring on the check valve is toward the inside before it is installed.
9.
Put gasket (12) and head (11) in position on the plate and install the two bolts that hold the pump together.
10.
Install the relief valve poppet (13), spring (14), the seal washer and cap (15) in the pump.
11.
Install O-ring seal (16) around the pump and put clean engine oil on it.
12.
Install drive coupling (17) on the pump shaft. end by: a) install fuel transfer pump
287
