3500 ENGINES
DISASSEMBLY AND ASSEMBLY WATER PUMP
INSTALL WATER PUMP
1361-12
1.
Make sure the gasket for the water line adapter and the O-ring seal on the pump are in position. Put clean engine oil on the O-ring seal. Fasten a hoist to water pump (1) and put water pump (1) in position on the engine. Make sure the splines on the pump shaft are correctly engaged and install the bolts to hold the pump to the oil and water pump drive adapter.
2.
Install bolts (2) to hold the pump to the water line adapter.
3.
Install damper guard (3) on the engine.
4.
Make sure the O-ring seals on both ends of tube (4) are in position and put clean engine oil on the seals. Put tube (4) in position and install retainers and bolts to hold the tube in position.
5.
Connect the water supply line to the water pump inlet.
6.
Fill the cooling system with coolant to the correct level.
275
