3500 ENGINES
DISASSEMBLY AND ASSEMBLY CRANKCASE BREATHER
REMOVE CRANKCASE BREATHER 1317-11 1. Remove the bolts from clips (2). Loosen the clamps that hold the hose assembly to the crankcase breather assemblies. Remove fumes disposal group (1) and the hose assembly as a unit from the breather assemblies.
2.
Remove four nuts (4) and remove breather assemblies (3) from the elbow.
3.
Remove cover assembly (5) from each breather assembly (3).
4.
Remove filter element (6) from each breather assembly (3).
5.
Remove O-ring seals (8) from elbow (7).
6.
Remove elbow (7) and the gasket from the front drive housing.
270
