3500 ENGINES
DISASSEMBLY AND ASSEMBLY AIR INTAKE SHUTOFF (3508)
3.
Install spacer (8) and spring (6) on shaft assembly (2). Install shaft assembly (2) in housing assembly (7). Make sure spring (6) is correctly engaged with dowel (I) as shown.
4.
Install handle (10) on the shaft assembly. Turn handle (10) up (upward) and install pin ( 11 ) so handle (10) can be put in contact with pin ( 1). With handle (10) in contact with pin (11), install plate assemblies (9) on the shaft assembly.
5.
Release handle (10) from the pin and remove the pin so plate assemblies (9) can move to the "SHUTOFF" position. A 0.076 mm (.003 in.) feeler gauge must not pass between plate assemblies (9) and the housing assembly as shown. Remove handle (10) from the shaft assembly.
6.
Put spacer assembly (12) in position and install pin (11) in the housing assembly through the spacer assembly.
