3500 ENGINES
DISASSEMBLY AND ASSEMBLY MANUAL SHUTOFF
REMOVE MANUAL SHUTOFF
1P1856
7418-11
Tools Needed Pliers
A 1
1.
Remove bolt (1) and the washer. Pull lever (2), the adapter and lever from the front drive housing. There is an O-ring seal that holds the adapter in the front drive housing.
2.
Remove bolt (3) and the washer to remove lever (2) from adapter (4).
3.
Use tool (A) and remove the ring that holds lever (5) in adapter (4). Remove lever (5) from adapter (4).
4.
Remove 0-ring seal (6) from adapter (4).
5.
Remove seal (7) from adapter (4).
257
