HYDRAULIC SYSTEM
ME12002
Hydraulic Pump Rotation Group
Figure 3-19 Rotation Group
NOTICE:The hydraulic pump is symmetrical,
(152) to lightly slide against shoe plate (211). See Figure 3-19.
for illustration purposes each part number is shown in Figure 3-19 only once. However, each part shown is also located on the other side of the hydraulic pump at the parallel location.
Cylinder springs (157) press pistons (151) and shoes (152) against shoe plate (211), and through setting plate (153) and spherical bushing (156). Cylinder springs (157) then press cylinder block (141) against valve plate (313). See Figure 3-19.
Rotation group consists of the following parts. See Figure 3-19 for identification. Drive shaft Cylinder block Pistons (9 qty.) Shoes (9 qty.) Setting plate Spherical bushing Cylinder springs Bearings
Swash Plate Group
(111) (141) (151) (152) (153) (156) (157) (123 & 124)
Swash plate group consists of the following parts. See Figure 3-19 for identification. Shoe plate Swash plate Swash plate bearings Tilt bushing Tilting pin Servo piston
Bearings (123 & 124) support drive shaft (111) at both ends. A splined (grooved) section connects drive shaft (111) to cylinder block (141). See Figure 3-19.
Swash plate (212) is a cylindrical plate located next to shoe plate (211). Swash plate bearings (251) support swash plate (212). See Figure 3-19.
Shoes (152) are shaped over the spherical end of pistons (151), forming a spherical ball joint. The shoe’s hydrostatic pocket counterbalances the pistons’ pressure hydraulic thrust, allowing the shoes
909768/BP1207
(211) (212) (251) (214) (531) (532)
Tilt bushing (214) is inserted into swash plate (212). The spherical portion of tilting pin (531), pre-assembled to servo piston (532), is inserted
