HYDRAULIC SYSTEM 1. Secure pads with height 30-50 mm under the bottom of housing (22). When installing cylinder drum (16), the shaft from cylinder drum (16) extends beyond the end of housing (22).
Installing the Oil Seal
1. Apply three bond (kk\1211” - white color) on outer surface of shaft seal (24). See Figure 3288.
2. Lubricate shaft seal (24) with grease. See Figure 3-288.
2. Using seal press insertion socket, secure shaft seal (24) into housing (22). See Figure 3-288.
3. Carefully install cylinder drum (16) into housing (22). See Figure 3-290.
IMPORTANT:Do not damage shaft seal (24) when installing the shaft of cylinder drum (16). 4. Check that locking ring (17) is held in place by the probe portion of piston centering plate (19). 5. Check that the end surface of cylinder drum (16) is about 7.5 mm lower than the top of housing (22). See Figure 3-290.
Figure 3-289 Housing 3. Install outer-race plate of taper roller bearing (1) into housing (22). See Figure 3-289. Installing the Cylinder Drum
Figure 3-291 Housing 6. Assemble lining plate (5) to friction plate (4). Apply hydraulic oil to each side. See Figure 3291.
IMPORTANT:Be sure to assemble lining plate (5) to friction plate (4) in the correct sequence.
Figure 3-290 Cylinder Drum
