ME12002
HYDRAULIC SYSTEM
Assembling the Cylinder
1. Lubricate grease on round area (contacting area with the locking ring [17]) of cylinder drum (16) and assemble locking ring (17). See Figure 3-285. 2. Install piston (18) into piston centering plate (19). See Figure 3-285. 3. Lubricate the inside of each piston cylinder using hydraulic oil. See “Hydraulic System” on page 30. See Figure 3-285.
Figure 3-286 Piston and Cylinder Drum
IMPORTANT:The end surface (A) of cylinder drum (16) is a sliding face. Protect the surface when installing cylinder drum (16) by using a soft cloth. See Figure 3-280. 4. Install piston (18) and return plate (19) onto cylinder drum (16). Assemble cylinder drum (16) and piston (18) according to the marks made in step 2 of “Removing the Cylinder Assembly” on page 192. See Figure 3-285 and Figure 3-286. 5. Lubricate specified hydraulic oil on the shoe sliding face of piston (18) and assemble sliding disk (20).
Figure 3-285 Cylinder Assembly Printed in U.S.A
195
909768/BP1207
