ME12002
HYDRAULIC SYSTEM
4. Using a driver and a hammer, remove shaft seal (24) from housing (22). See Figure 3-281.
5. Remove sliding disk (20) from piston (18). See Figure 3-282.
IMPORTANT:Do not reuse shaft seal (24)
IMPORTANT:Be sure to avoid damaging the
after removing it.
sliding face of sliding disk (20).
Disassembling the Cylinder 1. Remove the inner-race plate from tapered roller bearing (1). See Figure 3-281. 2. Set a gear extractor at two places of the innerrace plate of the tapered roller bearing and the spline end of the cylinder drum (16). 3. Remove the inner-race plate of tapered roller bearing (1). See Figure 3-281.
Figure 3-283 Locking Ring 6. Remove locking ring (17) from cylinder (16). See Figure 3-283.
Figure 3-282 Piston 4. Remove sliding disk (20), piston (18) and piston centering plate (19) from cylinder drum (16). See Figure 3-282.
Printed in U.S.A
193
909768/BP1207
