ME12002
HYDRAULIC SYSTEM
Port Connection - Dozer Blade Pedal
Disassembling the Pilot Control Pedal 1. Rinse the remote control valve in an alkanebased kerosene oil (or similar cleaning fluid).
T
2. Place blind plugs into all ports. 3. Secure the remote control valve into a vice. 501 201
P
Lift (1)
Drop (2)
Figure 3-218 Pilot Control Pedal
Figure 3-216 Dozer Blade Pedal - Port Connection
4. Remove bellows (501) from cover (201) as shown. See Figure 3-218.
Port Connection - Auxiliary Hydraulics T 472
Figure 3-219 Hexagon Socket Screw 5. Loosen hexagonal socket screw (472) using an Allen wrench. See Figure 3-219.
P 2
NOTICE:Adhesive (Loctite #241 or equiva-
1
lent) has been applied and the loosening torque is high. The loosening torque varies depending upon how the loctite cleaves.
Figure 3-217 Auxiliary Hydraulics - Port Connection
Printed in U.S.A
171
909768/BP1207
