ME12002
HYDRAULIC SYSTEM
Installing the Drive Shaft If roller bearings are assembled, proceed to “Installing the Oil Seal and Seal Cover” on page 94.
Figure 3-64 Tap Bearing with Plasticheaded Hammer 5. Use plastic-headed hammer to tap lightly on the outer rim of bearing to install drive shaft (111) assembly onto its support. See Figure 364.
Figure 3-62 Install Bearing Spacer
6. Complete steps 1-5 for both the rear and front pumps.
Figure 3-63 Drive Shaft 1. Install bearing spacer (127) onto drive shaft (111). See Figure 3-62 and Figure 3-63. 2. Install roller bearing (123) onto drive shaft (111). See Figure 3-63. 3. Install snap ring (824) onto drive shaft (111). See Figure 3-63. 4. Install drive shaft assembly (111), complete with bearing (123), bearing spacer (127) and snap ring (824), onto swash plate support (251). See Figure 3-63.
IMPORTANT:Do not use plastic-headed hammer to tap drive shaft (111) because damage may occur.
Printed in U.S.A
93
909768/BP1207
