Section 10. Firmware Configuration
Toyota Orderpicker Model 7BPUE15 Service Manual
FlashWare Program
FlashWare Program Overview The FlashWare program allows you to update software, configure options and troubleshoot electrical components on your Orderpicker truck through the following features: Flash memory program Clear primary memory Setup configurable items Options and serial number Learn throttle Diagnostics
ACAUTION We recommend using a surge protector (P/N 00590-43592-71) to protect your PC from possible electrostatic discharge or voltage surge.
3. Connect a standard 9-pin serial cable to
the surge protector. 4. Connect the cable to PT1 a t the top, outside edge of the steer/tractor manager. There is a cutout in the card cover for the cable.
Requirements FlashWare can be installed on an IBM-compatible PC. The PC communicates with the truck software through a 9-pin serial cable.
We recommend using a surge protector (P/N 00590-43592-71) to protect your PC from possible electrostatic discharge or voltage surge.
Install Flashware on PC If you are a customer service technician, obtain FlashWare from your Toyota Dealer. To install MashWare on the PC, double-click the installation file and follow the instructions on the screen. The software package is a self-extracting executable file. Read the "Readme" file in the software package for the latest detailed installation instructions.
Figure 10- 1 .
Steer/Tractor Manager (Cover Removed]
5. Turn the key switch ON.
Starting Flashware To start MashWare, click the desktop icon or via Start > Programs > Flashware.
FlashWare Functions Follow the instructions in the Online Help.
PC Connection to Truck 1. Turn the truck key switch OFF. 2. Connect the surge protector to the COM I or COM 2 port of your computer.
00700-C L2 2 2-05, 1 5 March 2 005
