Toyota Orderpicker Model 7BPUE15 Service Manual
Section 3. Systems Overview Vehicle Specification
Vehicle Specification Table 3- 1 .
General Information a n d Dimensions
24 Volt
Power unit 108.3 in.
2750 mm
40 in.
1016 mm
68.75 in.
1746.25 mm
Maximum usable battery compartment (L x W x H)
31 x 13 x 30.88 in.
787 x 330 x 784 mm
Maximum usable battery compartment with optional larger battery compartment (L x W x H)
36.88 x 14 x 30.88 in.
924 x 356 x 784 mm
Truck length Truck overall width (OAW) Turning radius
See Footnotea
Gradability Battery weight for alternate load capacity
920 lbs.
2000 lbs.
418 kg
908 kg
Battery weight
1600 lbs.
2000 lbs.
726 kg
908 kg
450 Minimum
Battery ampere-hours
I
I Maximum load capacity
Alternate load capacity
1085 Maximum 3000 lbs. to 216"
1361 kg to 5486 mm
2500 lbs. to 240-241"
1 135 kg to 6096 mm-612 1 mm
3000 lbs. to 240-241"
1350 kg to 6096 mm-6121 mm
a. The Model 7BPUE15 is designed for level floor operation only. It is capable of being driven in a fully lowered, unloaded condition on a maximum 100 ft. long ramp with a maximum incline of 6%.
