Section 8. Wire Guidance
Toyota Orderpicker Model 7BPUE15 Service Manual
Set-Up Procedure
Learn Guide Wire Frequency
Learn Wire Guidance Offsets
NOTE: Make sure the line driver is set up and adjusted properly.
NOTE: Make sure the line driver is set u p and adjusted properly.
1. In manual steer mode, position the truck to center the tractor end and the load end sensors over the guide wire (+ 0.75" [19 mm]).Make sure the drive unit is centered.
1. In manual steer mode, position the truck to center the tractor end and the load end sensors over the guide wire (+ 0.75" [19 mm]). Make sure the drive unit is centered.
NOTE: The horn chirps a t approximately 10 chirps per second when the truck is centered over the guide wire and if the present frequency has been learned previously.
NOTE: The horn chirps a t approximately 10 chirps per second when the truck is centered over the guide wire and has previously learned the present guide wire frequency.
2. Without moving the truck, turn the key switch off. 3. Enter horn code 3,3. a. Hold down the horn button and turn the key switch on. Do not release the horn yet.
2. Without moving the truck, turn the key switch off. 3. Enter horn code 3,4. a. Hold down the horn button and turn the key switch on. Do not release the horn yet.
b. Wait for the steer LEDs to stop flashing, and release the horn button.
b. Wait for the steer LEDs to stop flashing, and release the horn button.
c. Press and release the horn button 3 times. Each time you press the button, a n additional BDI LED will light.
c. Press and release the horn button 3 times. Each time you press the button, a n additional BDI LED will light.
d. Wait for the BDI LEDs to turn off.
d. Wait for the BDI LEDs to turn off.
e. Press and release the horn button 3 more times.
e. Press and release the horn button 4 more times.
f. Wait for the BDI LEDs to turn off.
f. Wait for the BDI LEDs to turn off.
4. Wait 10-15 seconds for the truck to learn
the guide wire frequency. During this time, the following occurs: BDI LEDs scroll up and down Horn does not chirp 5. After the BDI stops scrolling, verify the truck has learned the guide wire frequency. Observe the following pattern: Horn chirps a t approximately 10 chirps per second Center steer LED flashes continuously 6. If the truck fails to demonstrate the pattern listed in step 5, repeat the procedure.
4. Wait for the center steer LED to start
flashing. (The LED should start flashing in approximately 8 seconds.) 5. Step on the deadman pedal and wait for the drive unit to center. 6. Flip the auto/manual switch to auto. 7. Drive tractor-first for approximately 20 feet (6.1 m) and coast to a stop. NOTE: Do not apply the brake, or drive forks-first a t any time during this procedure.
Travel speed is limited to 2 mph (3.2 kph). The chirp pitch changes slightly. Left and right steer LEDs flash. 8. Flip the auto/manual switch to manual.
00700-CL222-05, 1 5 March 2005
