Section 8. Wire Guidance
Toyota Orderpicker Model 7BPUE15 Service Manual
Install Kit Components
Load Sensor Assembly
6. Connect the JW1 cable to the filter card.
1. Lift the platform, and securely place a safety stand under the platform. Lower the platform on the safety stand. 2. Turn key switch OFF and disconnect the battery.
3. Secure the antenna frame assembly (P/N 00590-02772-71) to the cross tie between the side cylinders with four hex head cap screws. See Figure 8-3. 4. Connect the 1L cable assembly (P/N 00590-02911-71) to the connector on the sensor assembly. See Figure 8-4.
Figure 8-4.
Figure 8-5.
JWI Cable Routing Under Battery to Tractor
Figure 8-6.
Bumper Plate, location
JW I Cable Connection
5. Route the cable along - the lift hose to the tractor. Add cable ties loosely as necessary to hold the cable to the hose. See Figure 8-5.
NOTE: Tight cable ties will cause the shielded sensor cable to break as the lift hose expands when the platform lifts.
Tractor Sensor Assembly 1. Remove the bumper plate. See Figure 8-6. 2. Place tractor sensor assembly (P/N 00590-02842-7 1) on the bumper plate with the connector jack facing the top of the bumper plate and secure with four screws (P/N 00590-03085-7 1). See Figure 8-7. 3. Connect cable assembly (P/N 00590-45746-71) to the sensor at connector J1T. See Figure 8-7. 4. Feed the cable through the cutout in the tractor frame along the right side of the tractor frame drive unit housing. Secure the cable to the tractor frame using the cable straps (P/N 00590-03458-71) and
