Toyota Orderpicker Model 7BPUE15 Service Manual
Section 7. Component Procedures
Hydraulic Components
Flow Control Valve
Flow Control Valve 7. Place the hydraulic fitting in the valve housing block with the O-ring end first and tighten. Install hydraulic tubing. Remove blocks and bleed the hydraulic system. See "Bleeding the Hydraulic System" on page 7-64. Connect power and test lift function befc returning truck to service.
Figure 7- 108. Flow Control Valve Location
Replace 1. Lift and block carriage enough to reach valve housing block. 2. Turn key switch OFF and disconnect the battery. 3. Remove hydraulic tubing. See Figure 7- 108.
4. Remove fitting. See Figure 7-108.
5. Pull out flow control valve. 6. Place the new valve in the housing.
Figure 7- 109. Replacing Flow Control Valve
NOTE: Follow the directional arrow on the flow control valve to install it correctly. It should be pointing out of the housing in the direction of flow. See Figure 7- 109.
00700-CL222-05, 1 5 March 2005
