Toyota Orderpicker Model 7BPUE15 Service Manual
Section 7. Component Procedures
Hydraulic Components 10. Remove seal from cushion. See Figure 7-100.
Side Cylinder 12. Install spring. Make sure it is fully seated in cushion piston. 13. Install cushion piston. 14. Install retaining ring and snap ring. 15. Install cylinder in truck. See "Side Cylinder" on page 7-65.
Figure 7- 10 1. Cushion Piston Seal Kit, listed In Order of
installation
Do not separate piston from piston plug unless necessary. If disassembly is required, use a strap wrench only. Do not damage piston surface.
NOTE: When repacking the cylinder, replace all packings. See Parts Catalog for packing kits. 11. Install seal kit on cushion piston. See Figure 7-10 1. Tip: Twisting the fiber rings prior to installation helps them retain their "memory." See Figure 7-102.
Figure 7- 102. Twisting Fiber Rings
00700-CL222-05, 1 5 March 2005
Figure 7- 103. Cushion Assembly
Cleaning 1. Flush inside of housing. 2. Wipe piston with clean kerosene or suitable industrial solvent.
3. Inspect all surfaces for galling or heavy scratches. Remove minor defects with a fine emery cloth. 4. Inspect all parts; replace a s necessary.
