Section 7. Component Procedures
Toyota Orderpicker Model 7BPUE15 Service Manual Electrical Components
Fuses
Auxiliary Power Fuses
Fuses Replacement When replacing fuses, make sure fuses are installed in the proper order. See Figure 7-76.
Figure 7-76.
Fuse Locations
NOTE: Refer also to "Fuses" on page 5-15.
Figure 7-78. Fuse Plate Mounting and Cable Routing
Installation 1. Turn key switch OFF and disconnect
battery. 2. Remove operator console cover. 3. Remove the front plate under the console from the operator platform. 4. Line u p the fuse block on decal and mark top and bottom holes.
Figure 7-77. Control Fuses on Steer/Tractor Manager
5. Punch out the holes. 6. Push the fuse block mounting screws through the holes in the decal. 7. Line up the screws with the mounting holes on the plate and adhere the decal to the plate. 8. Mount the fuse holder on the caution decal. Secure with two pan head screws. See Figure 7-79.
00700-CL222-05, 1 5 March 2005
