Section 7. Component Procedures Drive Motor
Toyota Orderpicker Model 7BPUE15 Service Manual Electrical Components
12. If pinion needs to be installed: a. Clean threads using thread primer (P/N 00590-04963-71). b. Install the key and gear. c. Apply adhesive (P/N 00590-04964-71)to the threads. d. Torque the n u t to 4 5 ft. lbs. (63 Nm). 13. Install a new gasket to the motor flange. 14. Install drive motor. 15. Install cam rings (if previously installed) and secure motor to drive unit with cap screws (13 mm socket). See Figure 7-56. 16. Install dipstick. See Figure 7-56. 17. Install steer motor and connect wires to steer power head. 18. Install brake if previously removed and connect wires. 19. Connect power cables to drive motor. See Figure 7-56. 20. Install tractor covers. See "Tractor Covers" on page 7-11. 21. Connect power and test truck operation before returning to service.
Figure 7-56.
Connecting Drive Motor to Truck Systems
00700-CL222-05, 1 5 March 2005
