DIAGNOSTIC CODE 1-7 Test 32
Test 64
Checking for a failed sensor
Checking for a damaged connector
1. Replace the coolant level sensor. 2. Reconnect the J1A, J1B, and J2 connectors. 3. Turn the ignition key to the ON position.
If code 1-7 is active, proceed to Test 64. If code 1-7 is no longer active, replacing the sensor has corrected the problem. Figure 54 — Inspect for Damaged, Broken or Missing Pins
1. Turn the ignition key to the OFF position. 2. Disconnect the J1A connector from the V-MAC II module. 3. Visually inspect for damaged, broken or missing pins on the J1A connector.
If damage is evident, repair or replace the J1A connector (if possible). If there is no evidence of damage, reconnect the circuit and turn the ignition key to the ON position. If the fault is still present, replace the V-MAC II module. If the fault is not present, the procedure has corrected the problem. Clean and inspect the connections.
