REPAIR AND ADJUSTMENT PROCEDURES CONTACT REMOVAL
Figure 335 — Contact Removal
1. With the rear insert toward you, snap the appropriate-size extractor tool over the wire of the contact to be removed.
CONTACT REPLACEMENT
2. Slide the tool along the wire into the insert cavity until it engages the contact and resistance is felt.
Use only the appropriate size Deutsch plastic tool. DO NOT use any other kind of tool.
Do not twist or insert the tool at an angle. 3. Pull the contact-wire assembly out of the connector.
Figure 336 — Deutsch Removal Tools
To replace a contact on a wire, use the Deutsch hand crimp tool, part No. HDT-48-00. 1. Strip approximately 1/4 inch of insulation from the wire.
