COUPLINGS, ADAPTERS AND ATTACHMENT KITS
1
2
1
2
BASE/LOAD CELL ADAPTERS
1
2
Catalog Number
Description
2501-113
Crosshead/base adapter, rated capacity: 100 kN 6 × M10 on 10OPC to 1/2 in accessory clevis-end fitting
2501-148
Crosshead/base adapter, rated capacity: 100 kN 6 × M10 on 10OPC to M48 × 2 LH accessory threaded-end fitting
2501-119
Adapter, rated capacity: 100 N, 1/2 in to 3/16 in accessory clevis-end fitting
2501-346
Adapter, rated capacity: 10 kN, 1/2 in to 6 mm accessory clevis-end fitting
2501-159
Adapter, rated capacity: 10 kN, 16 mm to 6 mm accessory clevis-end fitting
2501-338
Adapter, rated capacity: 100 kN, 1/2 in to 16 mm accessory clevis-end fitting
8000-025
M30LHm to 1/2 inch clevis pin (Type Df)
GRIP ADAPTERS
1
2
Catalog Number
Description
2501-194
Piggyback adapter, rated capacity: 100 kN, converts pneumatic wedge grips 2716-110, 2716-120 to M30×2 LH with 6 x M10 on 100 PCD
2501-208
Piggyback Load Cell Adapter for use with Type D load cell clevis. Allows the high capacity cell to remain bolted to the crosshead while a more sensitive, low capacity cell is installed. Bolts to load cell and provides a Type D f (1/2” clevis) attachment. For mounting 2580 Series load cells. Compatible with 500 N, 1kN, 1kN & 5kN capacities only.
2501-209
Piggyback Load Cell Adapter for use with Type D load cell clevis. Allows the high capacity cell to remain bolted to the crosshead while a more sensitive, low capacity cell is installed. Bolts to load cell and provides a Type D f (1/2” clevis) attachment. For mounting 2580 Series load cells. Compatible with 10kN, 30kN & 50kN capacities only.
2501-210
Piggyback Load Cell Adapter for use with Type D load cell clevis. Allows the high capacity cell to remain bolted to the crosshead while a more sensitive, low capacity cell is installed. Bolts to load cell and provides a Type D f (1/2” clevis) attachment. For mounting 2530 Series load cells. Compatible with 5 N, 10 N, 50 N, 100 N, 500 N, 1kN, 2kN & 5kN capacities only.
2501-235
Adapter for mounting 2530, 2525 or 2518 load cells on 338X floor model systems. The lower capacity load cell can be either connected to the 338X load cell or the 338X load cell can be removed and the lower capacity load cell can then be connected directly to the crosshead.
2501-256
Piggyback adapter, rated capacity: 300 kN, converts hydraulic wedge grips 2742-501, For mounting 2580 Series load cells. Compatible with 500 N, 1kN, 1kN & 5kN capacities only.
