11 Operation – ISOBUS Terminal 11.4 Basic setting (initialisation)
11.4.1 Starting the initialization process Danger! When raising/lowering the rotors, make sure that nobody is in the pivoting area. There is a risk of injury. – Direct all persons out of the danger area. – Switch off the machine at once, if necessary. 42
– If necessary, interrupt the control unit with the “STOP” key. Never work on the machine while the tractor's engine is running. – Switch off the engine. – Remove the ignition key.
• Turn the terminal on. See the operator's manual of the terminal being used or Switching on/off the CLAAS Communicator, see page 69.
43
Press the “Soft Key”. (Fig. 42) – The display switches to the “LINER 3000” start screen. – The submenu “Working Position” is active – the icon “Working Position” is shown inverted (Fig. 43). Switch to the “Maintenance” tab as follows: Press the “Soft Key” (Fig. 43). – The submenu “Maintenance” is opened – the “Maintenance” icon is shown inverted (Fig. 44). Press the “Soft Key” (Fig. 44).
44 – The display switches to the “Init” (Fig. 45)screen.
0293 133.7 - BA LINER 3000
97
