11 Operation – ISOBUS Terminal 11.1 Display
11.1.3 Menu bar The menu bar (2) shows the submenus available on the tabs. 2
The tabs are changed with the following soft keys: “next” = next menu,
S
“back” = previous menu – see Soft Key icons, page 77. The following icons are available in the menu bar: Road transport
3
Working position Maintenance Clearance height Program clearance height (headland) Rake height Working width: Information Running gear The icon (S) of the active submenu is shown inverted black/white, e.g.: Working position = not active, Working position = active. Note! The menus which are available depend upon the equipment fitted to the machines. The menus illustrated in the following figures are not always available. (Fig. 3)
76
BA LINER 3000 - 0293 133.7
