9 Driving and road transport
9 Driving and road transport 9.6 Working position with ISOBUS Terminal
9.6 Working position with ISOBUS Terminal Danger! When raising/lowering the rotors, make sure that nobody is in the pivoting area. There is a risk of injury. – Direct all persons out of the danger area. – Switch off the machine at once, if necessary. – If necessary, interrupt the control unit with the “STOP” key. Never work on the machine while the tractor's engine is running. – Switch off the engine. – Remove the ignition key.
• Preparatory procedures – see Before lowering into the working position, page 57. Attention! Blocked wheels on the swather can lead to damage of the swather's running gear, because the running gear cannot be swivelled. – Release parking brake on the tractor and on the rotary swather.
P
– Do not operate foot brake.
• Never actuate the foot brake and/or the parking brake while extending or retracting the outriggers. 71494
26
• If necessary secure the tractor with wheel chocks to prevent it from rolling.
• Release foot brake and parking brake. (Fig. 26) Note! For further information see the operator's manual of the terminal being used, or Operation – CLAAS Communicator, page 67. The symbols are explained in chapter 11 Operation – ISOBUS Terminal from page 75.
• Before switching on the control unit, the hydraulic system must be pressurized.
0293 133.7 - BA LINER 3000
59
