9 Driving and road transport 9.4 Before transport
Attention! 4
When the rotors are running, unsecured spring brackets (4) can be damaged. – Secure the spring brackets of the removed tine arms. From Serial No. 605 0 1858 onwards
5
3
• Fold the spring brackets (4) inwards and hook into the fixing screw (6). 19
• Remove the tine arms (3) from the tine arm mounts (5), and
• insert them in the racks (7). (Fig. 19, 21)
• If necessary, seal the ends of the mounting tubes – see Parking the machine at sub-zero temperatures, page 45. 6
4 20
7 65414
21
9.4.2 Swing lighting bracket upwards To allow the machine to pass through narrow entrances, the lighting bracket can be folded up. Proceed as follows:
1
• Swing warning plates (2) upwards, and • secure with a screw (1).
2
(Fig. 22)
22
56
BA LINER 3000 - 0293 133.7
