9 Driving and road transport
9 Driving and road transport 9.3 Transport position with operating terminal
9.3 Transport position with operating terminal Danger! When raising/lowering the rotors, make sure that nobody is in the pivoting area. There is a risk of injury.
1
– Direct all persons out of the danger area. – Switch off the machine at once, if necessary. – If necessary, interrupt the control unit with the “STOP” key (1) (Fig. 13). 13
73687
Never work on the machine while the tractor's engine is running. – Switch off the engine. – Remove the ignition key. Attention! In transport position, the PTO shaft must not be switched on, otherwise the PTO drive and the universal drive shafts may be damaged. – Switch off PTO shaft.
• Switch off PTO shaft. Attention! Blocked wheels on the swather can lead to damage of the swather's running gear, because the running gear cannot be swivelled. – Release parking brake on the tractor and on the rotary swather.
P
– Do not operate foot brake.
• If necessary, secure the tractor with wheel chocks to prevent it from rolling. 71494
14
• Release parking brake on the tractor and on the rotary swather.
• Never actuate the foot brake and/or the parking brake while extending or retracting the running gear. (Fig. 14)
• Switch hydraulic system to pressure.
0293 133.7 - BA LINER 3000
53
