9 Driving and road transport
9 Driving and road transport 9.2 Transport position with ISOBUS Terminal
9.2 Transport position with ISOBUS Terminal Danger! When raising/lowering the rotors, make sure that nobody is in the pivoting area. There is a risk of injury. – Direct all persons out of the danger area. – Switch off the machine at once, if necessary. – If necessary, interrupt the control unit with the “STOP” key. Never work on the machine while the tractor's engine is running. – Switch off the engine. – Remove the ignition key. Note! For further information see the operator's manual of the terminal being used, or Operation – CLAAS Communicator, page 67. The symbols are explained in chapter 11 Operation – ISOBUS Terminal from page 75.
• Switch hydraulic system to pressure. • Turn the terminal on. See the operator's manual of the terminal being used or Switching on/off the CLAAS Communicator, see page 69. Press the “Soft Key”. (Fig. 7) The tabs are changed with the following soft keys: 7
“next” = next menu, “back” = previous menu – see Soft Key icons, page 77. Note! The “Road transport” menu can be opened from all menus shown in the tab.
50
BA LINER 3000 - 0293 133.7
