8 Hitching/unhitching the machine 8.1 Hitching the machine
8.1.3 Prop stand Danger!
1
Any work under the chocked up swather may only be carried out if the machine has been properly secured – risk of injury. – Lower the prop stand fully to the ground, and secure it.
2
– Do not place an extra load on the prop stand by means of the tractor's hydraulics.
6
Raise the prop stand when the machine has been hitched. Proceed as follows to raise the prop stand: – Raise the machine slightly with the three-point hitch, to take the load off the prop stand. – Pull out pin (1), and push prop stand (2) upwards as far as it will go. – Secure the prop stand (2) by reinserting pin (1). Proceed as follows to lower the prop stand: – Raise the machine slightly with the three-point hitch. – Pull out pin (1), and lower prop stand (2) fully to the ground. – Secure the prop stand (2) by pushing pin (1) into the closest hole. (Fig. 6)
0293 133.7 - BA LINER 3000
33
