15 Maintenance 15.4 Drives
15.4.4 Assembling/dismantling the universal drive shaft protection Danger! Work on the drive shaft may only be carried out with the PTO disengaged and the engine switched off. – Remove the ignition key. Never operate the drive shaft without or with damaged guards. – Mount the joint guards and protective tubes. – Secure the guards against rotation. – Only use drive shafts that are in perfect technical condition. In order to remove the universal drive shaft and for greasing the joints, sliding surfaces and protection tubes, the universal drive shaft protection must be removed. For lubrication intervals and lubricant specification – see Lubricating chart, page 177. (Fig. 16)
16 Proceed as follows for removal of the universal drive shaft protection:
1
• Use a tool (e.g. a screwdriver) to release the
3
sleeve (2) from the protective funnel (1).
• Remove the fixing screws (3) (6x). (Fig. 17)
2 17
0293 133.7 - BA LINER 3000
157
