15 Maintenance 15.4 Drives
15.4.2 Angle drives Checking for leaks All drives must be checked regularly for leaks; check the lubricant level if necessary. Maintenance interval – see Maintenance schedule, page 147. Checking/changing the gear oil See the Lubricants chart, page 148 and the Maintenance schedule, page 147 for lubricant quantities and change intervals. Note! The indicated filling quantities are approximate values; the oil level check is always decisive to maintain a correct oil level. Checking the gear oil level:
• Remove the oil level check plug. Oil change:
• Remove the oil by suction. Environment! Ensure that the old oil is disposed of correctly. Rear angle drive 1 = oil filling and inspection hole 2 = oil drain plug (Fig. 14) 1
2 64603
14 Front angle drive 3 = oil filling and inspection hole 4 = oil drain plug
3
(Fig. 15)
64605
0293 133.7 - BA LINER 3000
4
15
155
