14 Trouble shooting
14 Trouble shooting 14.2 Error messages in the display (swather with ISOBUS Terminal)
14.2 Error messages in the display (swather with ISOBUS Terminal) Error message 1: Danger! When raising/lowering the rotors, make sure that nobody is in the pivoting area. There is a risk of injury. – Direct all persons out of the danger area. – Switch off the machine at once, if necessary. – If necessary, interrupt the control unit with the “STOP” key.
1
Never work on the machine while the tractor's engine is running. – Switch off the engine. – Remove the ignition key. Initialization is started with running/overrunning PTO shaft.
• Disengage the PTO shaft. – The display changes to the start window, seefig. 12, see 83.
• Press the “Soft Key”: The display changes to the start window, seefig. 12, see 83. The display changes to the info window, seefig. 16, see 84. (Fig. 1) Error message 2: The control system has recognised the following error: – The rotors should be automatically lifted above the max. headland position (transport position) with the PTO shaft running/overrunning. – The process is stopped.
• Disengage the PTO shaft.
2
– After the PTO shaft comes to a standstill the display changes to the screen “Automatically raise to transport position” seefig. 11, page 52. Push the “Soft Key”, the display changes to the start screen, see fig. 12, page 83. (Fig. 2)
0293 133.7 - BA LINER 3000
143
