13 Field operation 13.1 Using the swather
13.1.3 Changing the swath width 1 A
By locating the thrust rods (1) in one of the four holes (A - D), the swath width can be varied between 1.5 m (A) and 2.3 m (D).
2 B
C
Note!
D
The swath width can only be changed in the transport position. Secure the pin (3) with the spring clip (2). (Fig. 31)
3 68065
31
Note! If the thrust rod is located in hole A, the pin (3) cannot be secured with the spring clip (2) (Fig. 32).
1 A
B
C
D
(Fig. 32)
2 3 32
136
BA LINER 3000 - 0293 133.7
