13 Field operation 13.1 Using the swather
13.1.2 Using the machine with the control terminal Adjusting the working width (rotor overlap)
Swather with control terminal
The working width of the swather can be adjusted by means of the front rotors. If the working width is increased, the overlap between the front and rear rotors is reduced, and if the working width is reduced, the overlap is increased.
1
Caution! Do not adjust to less than the minimum working width – see Minimum working width, page 125.
Note! The newly adjusted working width is stored. After automatic approach of the working position from the transport position, the max. working width is reset. A smaller working width must be adjusted again. Adjustment of the working width is only possible in the working and headland positions. These adjustments can also be made while working.
73699
21 Increase working width Press the key to increase the working width.
• Hold the key down until the required position is reached. – The front outriggers are extended. – The indicator light (1) blinks.
22
0293 133.7 - BA LINER 3000
131
