12 Operation – Control terminal 12.3 Manual control
12.3.4 Raising/lowering the rotors Attention! The rotors can also be raised to the transport position with the manual mode. The front rotors may collide during this operation. – Retract front rotors first before raising them to the transport position. Raise the rear rotors
Lower the rear rotors
Lower the front rotors
Raise the front rotors
73706
• Hold the corresponding key down until the 20
required position is reached. Note! The raising height is not limited in the manual mode.
(Fig. 20, 21)
21
114
BA LINER 3000 - 0293 133.7
