12 Operation – Control terminal 12.3 Manual control
12.3.3 Running gear Attention! Blocked wheels on the swather can lead to damage of the swather's running gear, because the running gear cannot be swivelled. – Release parking brake on the tractor and on the rotary swather.
P 71494
– Do not operate the foot brake.
19
Do not lower the running gear when the swather is in the working position, as this could result in damage to the rotors. – Do not lower running gear if the swather is in the working position.
• Never actuate the foot brake and/or the parking brake while extending or retracting the running gear.
• If necessary, secure the tractor with wheel chocks to prevent it from rolling.
• Release parking brake on the tractor and on the rotary swather. Raising/lowering the running gear
• Hold the key down until the required position is reached. – Raise/lower the running gear – Releasing the key and then pressing it again toggles the function between raising/lowering. (Fig. 18, 19)
0293 133.7 - BA LINER 3000
113
