12 Operation – Control terminal 12.2 Adjustments using the control terminal
12.2.3 Clearance height at headland Bring swather to the working position – see Working position with operating terminal, page 62.
1
Press these two keys simultaneously for about 3 secs. – The blinking frequency of the indicator light (1) changes from slow to fast. – The rotors are raised to the last setting made for the headland position. The raising height of the rotors can now be changed.
73696
13
14
108
BA LINER 3000 - 0293 133.7
